SOLAR CHARGE CONTROLLER
Solar Street Llight Charge Controller
Smart-3.2V Series
PWM, 15A, 3.2V/6.4V, Lithium solar controller.
2.4G wireless remote control/Infrared sensing/Microwave induction;
Intelligent solar controller, is programmable and especially for buck mode LED solar street light system.
It includes constant current driver function, which can make the cost of the whole system much lower.
Main Features
Can output constant current, output current can be set.
Automatic power balance 365 mode, 365 days can be lit.
Can read parameters and running status
Suitable for one or two Lithium batteries in series
lf battery voltage is low, it can be set to dimming
Dimming start voltage and percentage can be set
Auto sleeping during transportation
Low temperature charging protection
Charging target voltage and ecovery voltage can be set
Day/Night threshold can adjust automatically
Remote Unit to configure, with LCD display
5 stages time and dimming can be adjusted
lp67, Strong and durable aluminum case
Full automatic electronic protect function
Datasheets
| Item | Standard product | SMR1006-CCN32Li |
| Suffix description | G: 2.4G wireless remote control (default infrared remote control without suffix); R: Infrared sensing; V: Microwave induction; | |
| Max Charging Current | 15A | |
| Charging voltage target | 3.0~9.0V(Programmable) | |
| Charging voltage recovery | 2.9~8.9V(Programmable) | |
| Low voltage disconnect | 2.4~7.2V(Programmable) | |
| Low voltage reconnect | 2.6~7.4V(Programmable) | |
| Battery Type | Lithium | |
| 0℃ Charging protection | Yes、No、Slow(Programmable) | |
| Max volt on Bat. Terminal | 10V | |
| Max volt on PV terminal | 7V(Single cell), 15V(Two lithium batteries in series) | |
| Dusk/Dawn detect volt. | 1.0~3.0V(Programmable) | |
| Day/Night delay time | 0~30min(Programmable) | |
| Output Current | 0.3~10A(Programmable) | |
| Max. Output Power | 30W | |
| Min. Current | 0.3A（Dimming) | |
| Current precision | ±2% | |
| Dimming | 0~100%(Programmable) | |
| Auto dimming | Yes, NO(Programmable) | |
| Voltage of start dimming | 2.8~ Charging voltage target (Programmable) | |
| Dimming percentage | 5~40%(Programmable) | |
| Induction delay off time | 10~150s(Programmable) | |
| Communicaion | Infared/2.4G/Microwave | |
| Self consumption | 15mA@3.2V(Transportation mode) | |
| Dimensions | 82*45*18.6mm | |
| Weight | 125g | |
| Wire size | 2.5~4mm2 | |
| Ambient temperature | -35~+60℃ | |
| Ambient humidity | 0~100%RH | |
| Protection degree | IP67 | |
| Max Altitude | 4000m | |
